Fendt 1000 Series
Built to pull the heaviest of loads and plow the toughest of fields, the Fendt 1000 Series is made for heavy draft work. It’s packed with horsepower, yet still maintains its economical fuel consumption, easy maneuverability and superior comfort. This tractor embodies everything about the high standard Fendt is famous for.
Features:
- 396 to 517 hp engine
- Fendt VarioDrive
- 30,666 lbs. of unladen weight up to 50,706 lbs permissible
- 60 in. track available
- Completely roadworthy- up to 60 km/hr
- Optional rear PTO 1000 & 1000E
- Optional rear linkage
- All hitch systems in modular design
- Reverse drivers station option
Models
MODELS | PTO HP | ENGINE | TRANSMISSION | WEIGHT (lbs) | WHEELBASE | HEIGHT |
1038 Vario | 396 | MAN 12.4L | CVT | 30,865 | 130″ | 137″ |
1042 Vario | 435 | MAN 12.4L | CVT | 30,865 | 130″ | 104-1/2″ |
1046 Vario | 476 | MAN 12.4L | CVT | 30,865 | 130″ | 140-1/2″ |
1050 Vario | 517 | MAN 12.4L | CVT | 30,865 | 130″ | 140-1/2″ |
Fendt iD
- Concept of delivering high power at low engine speeds to the components of the tractor
- Conserves fuel; reduces wear
Fendt VarioDrive
- Drivetrain operates both axles independent of each other
- Variable four wheel drive allows torque to be controlled and distributed to each of the axles as needed
- Keep speed low while maintaining high engine power- regardless of ground conditions
- Drag losses are eliminated because the clutch decouples the front axle drive at 24 kph- giving you exceptional pulling power
Fendt “Pull-in-turn” effect
- No fixed drive ratio allows the front wheel drive to pull the tractor into the curve; reducing turning circle by 10%
Fendt Vario Grip
- Regulate tire pressure directly from the terminal
- Adjust to suit field or road operations
- Lowering the tire pressure in the field reduces compaction and improves grip
Technology
FENDTONE OPERATOR’S STATION
MULTI-FUNCTION JOYSTICK
This is located on the left of the armrest and is ergonomically designed specifically with operator comfort in mind. Because of its intelligent design, it enhances comfort and to reduces operator strain.
Used for controlling
- Vehicle direction and speed
- Hydraulic controls
- ISOBUS controls
- Headland automation
- Engine transmission and controls
- Features 4 freely assignable buttons (white)
3L JOYSTICK
This is found in the centre of the armrest and is located to the left of the multi-function joystick. This joystick is designed specifically for the operator to control loader applications
PUSH DIAL CONTROL
In order to reduce operator strain, this is now located to the right of the armrest and allows the operator to control monitor buttons and change parameters.
ARMREST CONTROLS
In order to be easily recognized, the controls are colour coded to represent different functions. In addition to the standard buttons, there are also five customizable buttons.
- Orange: Powertrain
- Blue: Hydraulic & 3pt
- Yellow: PTO functions
- Teal: ISOBUS & Teach-In functionality
- White: Freely customizable
- Headland management
- SectionControl eliminates overlapping
- ISOBUS capable implements
- Seamless integration with RTK
- Variable rate control (VRC) allows you to save operating inputs on the field database and automatically execute during operation
- Variable rate control (VRC) allows you to save operating inputs on the field database and automatically execute during operationHydraulics
- Dual circuit hydraulics combine to deliver high flow at 113.5 GPM and can be prioritized according to need
- Flexible (flat face coupling) allow you to use different coupling sizes (1/2", 3/4", 5/8")
- Rear options include power beyond, ISOBUS socket, rear return, PTO and rear linkage
