Geringhoff TruFlex Razor Draper Header
The Geringhoff TruFlex Razor Draper Header is designed to deliver exceptional harvesting performance with advanced flexibility, smooth crop flow, and precise ground following. Featuring a 3-section flex-point reel and frame combined with a flexible cutterbar, the TruFlex Razor adapts to changing field conditions while helping producers maintain consistent harvesting performance.
Built for versatility across a wide range of crops, the TruFlex Razor offers excellent contouring, reliable crop pickup, and efficient feeding performance. The header’s height control system for grain and soybean harvesting allows operators to harvest closer to the ground while maintaining control through a separate terminal for convenient adjustments in the field.
For producers harvesting canola and larger crops, the optional canola kit helps improve harvesting efficiency and reduce crop losses. Combined with features such as the large centre-fed auger, wide centre belt, deep belts, and optional Integrated Air System (IAS), the TruFlex Razor is engineered to handle demanding harvest conditions with confidence.
- 3 section frame contours to uneven terrain
- Exceptional crop flow in all conditions
- Cutting angle adjustment
- Narrow 4 inch side panels due to central cutterbar drive
- Easy-open side panel door
- Tool-free changing of the dividers
- Large center fed auger
- Widest center belt on the market
- Adjustable belt speed
- Deep belts
- Hydraulic knife drive
- Double knife system with overload protection
- Actuated gauge wheels to better hug the ground
- Optional Integrated Air System (IAS) fully integrated air system for increased yield potential
- Optional large cross auger and canola kit
- Optional high stubble kit for harvesting small grains
Specifications
| Model | Working Width | Outer Width | Reel Type | Frame Type | Flex Range | Cutter Bar | Total Weight |
|---|---|---|---|---|---|---|---|
| TFR 35 | 35 ft 1.3 in | 35 ft 9.1 in | 3-section | Flexible | 26.5 in | Flexible | 8,598 lbs |
| TFR 40 | 40 ft 0.3 in | 40 ft 9.0 in | 3-Section | Flexible | 31.0 in | Flexible | 9,149 lbs |
| TFR 45 | 44 ft 11.4 in | 45 ft 8.8 in | 3-Section | Flexible | 36.0 in | Flexible | 9,480 lbs |
2 Year Warranty & Extended Warranty
Upgrading your warranty is as simple as 1, 2, 3!
In addition to Geringhoff’s best-in-class, standard 2-year warranty, Geringhoff Warranty Extension allows you to extend your warranty for an additional 1, 2, or 3 years. That’s up to 5 years of total warranty coverage!
- 1, 2, or 3 years of extended coverage
- Parts and labour covered
- Low claim deductible
- Hassle-free processing
For more details, visit:
www.Geringhoff.com/warrantyextension
Frequently Asked Questions About the Geringhoff TruFlex Razor Draper Header
What makes the Geringhoff TruFlex Razor Draper Header different?
The Geringhoff TruFlex Razor combines a 3-section flex-point reel and frame with a flexible cutterbar to provide excellent ground following and harvesting performance. This design helps the header adapt to uneven terrain while maintaining smooth crop feeding.
What crops can the TruFlex Razor Draper Header harvest?
The TruFlex Razor is designed for versatile harvesting applications, including grain, soybeans, canola, and other large crops. Optional equipment packages allow producers to customize the header for their specific crop conditions.
How does the TruFlex Razor improve crop flow?
The TruFlex Razor uses a large centre-fed auger, wide centre belt, deep belts, and adjustable belt speed to provide smooth and consistent crop movement into the combine in a variety of harvesting conditions.
How does the TruFlex Razor follow uneven field conditions?
The TruFlex Razor features a 3-section flexible frame, flexible cutterbar, and actuated gauge wheels to help the header follow ground contours and maintain consistent cutting performance.
What is the benefit of the TruFlex Razor height control system?
The height control system for grain and soybean harvesting helps operators harvest closer to the ground while maintaining precise control through a separate terminal for easy adjustments.
Is a canola kit available for the Geringhoff TruFlex Razor?
Yes. The optional canola kit is designed for efficient and almost loss-free harvesting of canola and larger crops. The kit includes two side-mounted vertical knives and a large cross auger to improve crop handling and feeding performance.
What is the Integrated Air System (IAS) on the TruFlex Razor?
The optional Integrated Air System (IAS) provides a fully integrated air system designed to help improve crop capture and increase yield potential, especially in sensitive crops.
What maintenance features are included on the TruFlex Razor?
The TruFlex Razor includes convenient maintenance features such as an easy-open side panel door, tool-free divider changes, hydraulic knife drive, and double knife system with overload protection.
What warranty coverage is available for the Geringhoff TruFlex Razor?
The TruFlex Razor includes a standard 2-year warranty, with extended warranty options available for an additional 1, 2, or 3 years, providing up to 5 years of total warranty coverage.
